REKOR EDGE FLEX™

Portable data collection for temporary traffic studies

Rekor Edge Flex™ is a non-intrusive, portable data collection system that captures up to six lanes of high-speed roadway data and transforms it into holistic traffic insights accessible within the Rekor Discover™ platform.

The system is perfect for short-term traffic studies lasting one to seven days and provides vehicle category classification, vehicle counts, and speed reports that adhere to TMG standards.

Rekor Edge Flex system with a 4K camera attached to an adjustable pole
Rekor Edge Flex camera system deployed on the side of a road in New York City
PORTABLE TRAFFIC DATA COLLECTION

Deploy safely roadside without disrupting traffic

In 30 minutes or less a Rekor Edge Flex system can be readily deployed on the side of the road without the need for workers to enter unsafe conditions, cut into the pavement, or disrupt traffic.

View specifications

Unlock powerful performance

Up to 6 lanes of coverage

130 ft max capture distance

140 mph capture speed

1080p resolution camera

On-device video processing

Optimized infrared illumination for nighttime performance

Receive advanced traffic analytics

FHWA 13-bin vehicle category classification

Vehicle counts organized by state, time of day, and volume

Vehicle speed reporting by time of day and volume

Designed for temporary studies lasting 1 to 7 days

Operate in nearly all conditions

Outdoor rated, IP65, NEMA4 enclosure

4G LTE, Wi-Fi, Ethernet, and GPS connectivity

Battery powered to readily support deployments of 72 hours or more

Portable design for deployment in 30 minutes or less at roadside

PORTABLE TRAFFIC DATA COLLECTION

Capture and analyze traffic streams in real-time

How does the system work with live video of traffic?

Each Rekor Edge Flex system contains an embedded Edge Processing Unit (EPU) that processes multiple streams of high-resolution live video utilizing AI to transform that video into multi-faceted, actionable information. The Edge Flex also contains a high definition PTZ camera for easy setup which is also optimized for nighttime performance. Finally, the system runs on long lasting batteries that are easily swappable without any interruption.

What happens after the video is processed?

After processing the raw video using our EPU, the video stays securely stored on the device and small bits of metadata containing actionable information are sent to the cloud via a cellular connection. The data can then be accessed through REST APIs, exported in a variety of TMG-friendly formats, or viewed with Rekor Discover’s web-based dashboards.

Rekor Edge Flex vector diagram
REKOR DISCOVER™ SOFTWARE PLATFORM

Receive advanced traffic insights

Rekor Discover’s primary Class, Count, and Speed application provides critical insights and Per Vehicle Records (PVR) that fulfill many FHWA reporting requirements and help users make better-informed decisions.

Learn more
Bar graph showing vehicle types

Vehicle category classification

Vehicle classes categorized using FHWA's 13 or 6-bin standards

Line graph showing traffic by time of day

Traffic and vehicle counting

Total average daily traffic (ADT) and location-specific vehicle counts

Line graph showing speeds of vehicles

Speed reporting

Vehicle speeds with maximum, minimum, and 85th percentile values

Our SYSTEMS

Systems built for all environments

Rekor Edge Series features two models that enable vehicle classification and traffic data collection for countless use cases.

Choose a system that's right for you

Not sure which system to select? Talk to our experts today.

Rekor Edge Flex™

Rekor Edge Flex system with a 4K camera attached to an adjustable pole
Short-term traffic studies
Request a quote

Rekor Edge Max™

Rekor Edge Max cameras mounted to a pole
Long-term traffic studies
Learn more

Mode of delivery

Portable
Fixed

Capture distance (max)

130 feet
130 feet

Lane coverage (max)

6 lanes
6 lanes

Capture speed (max)

140 mph
140 mph

Camera resolution

1080p
1080p

Day/night operation

Green checkmark
Green checkmark

Communications

Connectivity

4G LTE, Wi-Fi, Ethernet
4G LTE, Wi-Fi, Ethernet

GPS

Green checkmark
Green checkmark

Security

AES 256, TLS & SSL-based encryption
AES 256, TLS & SSL-based encryption

Mount and power

Mounting style

Pole
Flexible

Runtime

72 hours
Continuous

Solar power

Red X
Optional

Environmental

Enclosure

NEMA4, IP65 rated polycarbonate
Die-cast aluminum, IP65

Ambient temperature

0°F to 115°F
0°F to 115°F
REQUEST A QUOTE

Ready to receive better roadway intelligence?

With a large inventory of devices and a nationwide team of skilled technicians, Rekor is ready to meet all demands with a rapid deployment schedule.
