REKOR EDGE MAX

Fixed license plate and vehicle recognition (ALPR)

Engineered for public safety missions and traffic speeds up to 120 mph, the Rekor Edge Max system for ALPR is deployed on the roadside of bidirectional primary roads and highways. It captures and processes license plate and vehicle data on-device within a durable enclosure and automatically sends recognition data to the Rekor Scout® software platform.

Rekor Edge Max cameras mounted to a pole

Unlock powerful performance

Up to 6 lanes of coverage*

300 ft max capture distance*

120 mph capture speed*

1080p resolution camera(s)

On-device video processing

Optimized infrared illumination for nighttime performance

State-of-the-art recognition

Advanced vehicle recognition with plate, make, type, color, and direction of travel

Accurate in day/night and all weather conditions

Read paper, temporary, and vanity plates

Real-time alerting on vehicles of interest

Operate in nearly all conditions

Outdoor rated, IP65 enclosure

4G LTE, Wi-Fi, Ethernet, and GPS connectivity

Operates on direct AC or solar power with continuous runtime

Permanent design for long-term safety initiatives

*Actual performance will vary based on proper calibration and site selection.
FIXED ALPR & VEHICLE RECOGNITION

Incredible license plate recognition accuracy

How does the system work with live video of traffic?

Each Rekor Edge Max system contains an embedded Edge Processing Unit (EPU) that processes multiple streams of high-resolution video at once. Installed directly on the roadside, it delivers low-power computing in a compact unit, allowing us to accurately analyze license plates and vehicles from full-frame video without performing expensive processing in the cloud.

What happens after the video is processed?

After processing the raw video using our EPU, small bits of metadata containing actionable information are sent to the cloud via a low-bandwidth cellular connection. The data can then be easily accessed in Rekor Scout’s web-based dashboards.

Rekor Edge Max vector diagram showing all components that make up the system
REKOR SCOUT SOFTWARE PLATFORM

Access and search all vehicle attributes

Built using advanced artificial intelligence with 6+ years of machine learning, Rekor Scout provides a vehicle’s license plate number, make, model, color, and direction of travel in a searchable dashboard.

Learn more
Searchable database screenshot in Rekor Scout

Searchable database

Conduct advanced searches based on full, partial, or missing plate numbers and vehicle attributes.

Live map view dashboard screenshot in Rekor Scout

Live map view

Look across your entire jurisdiction to pinpoint exactly where a license plate or vehicle was last seen.

Date picker calendar on a dashboard overlaid on top of picture of traffic

Flexible data retention

License plate and vehicle data is stored based on your policies with easy access and search filters.

Our SYSTEMS

Systems built for all environments

Rekor Edge Series features two ALPR models to enable license plate and vehicle recognition for countless use cases.

Choose a system that's right for you

Not sure which system to select? Talk to our experts today.

Rekor Edge Pro

Rekor Edge pro camera system
Businesses & neighborhoods
Learn more

Rekor Edge Max

Rekor Edge Max cameras mounted to a pole
Primary roads & highways
Request a quote

Installation method

Mountable
Fixed

Capture distance (max)*

75 feet
300 feet

Lane coverage (max)*

1 lane
3 - 6 lanes

Capture speed (max)*

70 mph
120 mph

Camera resolution

1080p
1080p

Dual-camera configuration

Optional

Day/night operation

Communications

Cellular service

Optional

Cellular modem

3G, 4G LTE MIMO

GPS

Ethernet port

Security

SSL & HTTPs
SSL & HTTPs

Mount and power

Mounting style

Surface or pole
Surface or pole

Power consumption

Avg: 7W, Max: 26W
Avg: 25W, Max: 30W

Solar power

Optional
Optional

Environmental

Enclosure

Die-cast aluminum, IP67
Die-cast aluminum, IP65

Operational temperature

-4°F to 122°F
-22°F to 131°F

Storage temperature

-22°F to 140°F
-40°F to 149°F
*Actual performance will vary based on proper calibration and site selection.
